Nominal Cable Dimensions: 14.2mm / 0.55 inches PVC Insulation Thickness: 0.76 mm / 0.029 inches The wire size chart below shows allowable ampacities of insulated conductors rated up to and including 2000 Volts, 60☌ through 90☌ (140☏ through 194☏), not more than three current-carrying conductors in raceway, cable, or earth (directly buried), based on ambient air temperature of 30☌ (86☏). Soft, bare copper solid per ASTM B3 and stranded per ASTM B3 and B8ģ0 mil color coded PVC sheath rated 90C is applied over the completed assembly 8/3 NM-B Cable Specifications*: Stranded 8 AWG and larger annealed soft bare copper per ASTM B3 and B8.Ĭolor coded polyvinyl chloride (PVC) compound with a nylon covering meeting the required thickness of Type THHN. Solid 14 to 10 AWG annealed soft bare copper per ASTM B3. UL 83: Thermoplastic Insulated Wires and Cablesįederal Specification A-A-59544 and requirements of the NEC.
Meets or exceeds all applicable ASTM specifications Find many great new & used options and get the best deals for Southwire 50 ft. 50 MC 8/3 Type 8 AWG 3 Conductors Stranded METAL CLAD Cable With Aluminum Armour and Green Insulated Ground Wire Copper.
#50 ft 8 3 wire portable#
GearIT 8/3 8 AWG Portable Power Cable (50 Feet - 3 Conductor) SOOW 600V 8 Gauge Electric. SOUTHWIRE COMPANY LL 63949202 Romex Type Nm-B Wg Non-Metallic Wire, 125 ft. NM-B cables are LEAD FREE and RoHS compliant. Southwire Romex SIMpull 8 / 3 Stranded Indoor Non-Metallic Wire. It may be fished through masonry or tile walls, where not exposed or subject to excessive moisture or dampness. NM-B is rated at 600 volts and although it is rated at a conductor temperature of 90☌ dry, its ampacity is limited to 60☌ according to the NEC 2008 and NEC 2011. Its applications are outlined in NEC 2008 and NEC 2011 Article 334. Non-metallic sheathed NM-B cable is used in normally dry installations in residential wiring, as branch circuits for outlets, lighting and other residential loads.
